MODEL 3215 3219 3220 3226
Weight * 1090 kg 1170 kg 1583 kg 1864 kg
Width
Length
Platform Size
Stowed Platform Height 0.88 m 0.99 m 0.97 m 1.15 m
Platform Elevated Height 4.6 m 5.8 m 6.1 m 7.9 m
Working Height 6.4 m 7.6 m 7.92 m 9.75 m
Stowed Height Railings Up 1.88 m 1.99 m 2.02 m 2.2 m
Drive Height (All Standards)
Lift Time (No Load) 18 sec. 20 sec. 27 sec. 43 sec.
Lower Time (No Load) 32 sec. 39 sec. 41 sec. 52 sec.
Lift Time (Rated Load) 23 sec. 25 sec. 33 sec. 56 sec.
Lower Time (Rated Load) 24 sec. 29 sec. 29 sec. 42 sec.
High Travel Speed 3.9 km/h
Elevated Drive Speed 1 km/h 1.1 km/h
High Torque Drive Speed 1.9 km/h 2.14 km/h
Gradeability
Tires (Solid Rubber)
60156AJ-AS-1
1.05 km/h
3.2 km/h
Height
0.81 m
N/A
* Weight with standard 0.9 m or 1.2 m extension platform.
Refer to nameplate for aerial platforms with 1.5 m or 1.8 m extension platform.
12 x 4 x 8 16 x 5 x 12
23% 25%
0.84 m
1.78 m 2.32 m
0.66 x 1.57 m 0.71 x 2.13 m
FULL
Standard Operating Time
Chassis
