Skyjack 4632 - Page 173

SECTION 6, Page 91
SJIII Series - The Conventionals 129919
Figure 6.4-5. Main Manifold Assembly
Index
No.
Skyjack
Part No.
DescriptionQty.
A 122272 1 MANIFOLD ASSEMBLY, Main
B 124253 - • ASSEMBLY, Manifold (Without directional valves)
1 107354 1 • • BLOCK, Main manifold
108052 9 • • • PLUG, Expander
2 106273 1 • • VALVE, 3-Way (lift)
3 105610 1 • • COIL, 24 Volt
4 104133 1 • • VALVE, Counterbalance
5 114580 1 • • FITTING, O ring fitting 45° #6 orb - #6
6 103069 AR • • FITTING, Connector #6 orb - #6
7 104437 6 • • FITTING, Plug #6
8 103623 1 • • VALVE, 3-Way (brake)
9 103605 2 • • COIL, 24 Volt
10 115320 1 • • FITTING, Plug #8
11 104534 2 • • VALVE, Relief
12 103655 1 • • VALVE, N.C. (lowering)
13 107666 1 • • FITTING, Cap nut
14 102856 1 • • FITTING, Plug #3 (Model 32XX only)
15 104419 1 • • FITTING, 1/16” NPT Plug
16 114581 1 • • FITTING, Tee #6 orb - #6 - #6
17 114579 1 • • FITTING, Tee #6 orb - #6 - #6
18 114578 2 • • FITTING, Elbow
19 128798 2 • VALVE ASS’Y, 24 Volt “Hytos” (Drive & Steer)
128317 1 • • VALVE ASSEMBLY, 12V Spool
128320 2 • • • COIL, 24 Volt
103920 4 • • BOLT, Socket head #10 - 24 x 2" Gr. 5
20 (Ref.) 1 VALVE ASSEMBLY, Drive cross over relief (Option)
121877 1 • MANIFOLD W/RELIEF VALVES, Cross-over
103923 4 • BOLT, Socket head #10 - 24 x 3.5” Gr. 5
21 701956 2 FITTING, Connector (Equipped with powered extension platform)
22 122427 1 KIT, Quick Disconnect (If Equipped)
122385 1 • QUICK DISCONNECT, Coupler
114521 1 • COVER, Quick disconnect dust
122364 1 • FITTING, Tee #6 - #6 - #6
23 122420 1 KIT, Quick Disconnect (If Equipped)
122385 1 • QUICK DISCONNECT, Coupler
114521 1 • COVER, Quick disconnect dust
122428 1 • FITTING, #6-#6
24 119825 4 CONNECTOR, With Diode
25 122213 1 ORIFICE, 1/16” NPT x 0.073”ID (Model 4620 only)
105530 1 ORIFICE, 1/16” NPT x 0.081” ID (Model 4632 only)
