SECTION 6, Page 93
SJIII Series - The Conventionals 129919
Figure 6.4-6. Hydraulic Hose Connections - Hydraulic/Electric Tray
Index
No.
Skyjack
Part No.
DescriptionQty.
A (Ref.) 1 All 32XX models and for model 46XX with serial number 713314 and Below
B (Ref.) 1 Model 46XX with serial number 713315 and Above
1 (Ref.) 1 PUMP AND MOTOR ASSEMBLY
- (For components, refer to Figure 6.4-2)
2 102665 1 FITTING, Connector #12 orb - #6
3 119851 1 HOSE, Suction 3/4”
*4 136563 1 HOSE ASSEMBLY, Filter to main manifold
5 109052 1 FITTING, Connector #12 orb - #6
6 (Ref.) 1 FILTER ASSEMBLY, Return
- (For components, refer to Figure 6.4-1)
7 (Ref.) 1 LOWERING VALVE/MANIFOLD
- (For components, refer to Figure 6.4-1)
*8 106412 1 HOSE ASSEMBLY, Pump to proportional manifold (13” long)
(If equipped with Internal Compensator Valve)
115318 1 HOSE ASSEMBLY, Pump to proportional manifold (11” long)
(If equipped with External Compensator Valve)
9 103069 1 FITTING, Connector #6 orb - #6
*10 112631 1 HOSE ASSEMBLY, Manual lowering valve manifold
11 114402 2 CLAMP, Worm #12
12 (Ref.) 1 MANIFOLD ASSEMBLY, Proportional control
- (For components, refer to Figure 6.4-4)
*13 107732 1 HOSE ASSEMBLY, Proportional manifold to return filter (28” long)
(If equipped with Internal Compensator Valve)
111196 1 HOSE ASSEMBLY, Proportional manifold to return filter (18” long)
(If equipped with External Compensator Valve)
*14 106413 1 HOSE ASSEMBLY, Main manifold to proportional manifold
15 (Ref.) 1 MANIFOLD ASSEMBLY, Main
- (For components, refer to Figure 6.4-5)
*16 126331 1 HOSE ASSEMBLY, Cushion cylinder
17 114578 2 FITTING, Elbow 90° #6 orb - #6
*18 102647 1 HOSE ASSEMBLY, Cushion cylinder
19 (Ref.) 1 CYLINDER, Cushion
- (For components, refer to Figure 6.4-1)
20 (Ref.) 1 HOSE ASSEMBLY, Main Case Drain B
- (For components, refer to Figure 6.3-10)
21 702382 1 FITTING, Swivel Run Tee - #6 JIC B
* 136562 1 KIT, Hydraulic Hose
