SECTION 6, Page 97
SJIII Series - The Conventionals 129919
1 117513 1 WELDMENT, Battery tray (If equipped with Fuse Box)
143665 1 WELDMENT, Battery tray (If equipped with Inline Fuse)
2 119609 1 LATCH, Tray Assembly
102781 1 • LATCH, Rotary
111534 1 • KNOB, Latch
103855 1 • BOLT, Hex Head 1/4” - 20 x 1/2” Grd. 5
104000 1 • WASHER, Lock 1/4”
103864 3 • BOLT, Hex Head 5/16” - 18 x 1” Grd. 5
103404 3 • WASHER, Lock 5/16”
3 119528 1 ASSEMBLY, Tray Lock
104049 1 • BRACKET, Tray Lock
104051 1 • CAM, Lock
103886 1 • BOLT, Hex Hd 5/16”-18 x 1.50” Grd. 5
4 125800 1 SCREW, Slotted Round Head 3/8” - 16 x 1” Gr. 5
108575 1 NUT, Jam 3/8” - 16 Gr. B
5 126236 1 WEIGHT, Battery Charger
6 119286 1 BRACKET, Connector Mount
7 113655 3 PLYWOOD, 1/4” x 9.5” x 29”
8 113654 5 PLYWOOD, 1/4” x 9.5” x 10.5”
9 (Ref.) 1 CHARGER, Battery Assembly
(For components, refer to Figures 6.5-3)
10 106552 4 BATTERY, 6V (Interstate #U2500)
103480 4 BATTERY, 6V (Interstate #U2200)
11 119591 1 ASSEMBLY, Cable (Battery to Fuse Box) (If equipped with Fuse Box)
105534 1 • PLUG, Battery Connector 175 Amp 2-prong
103036 1 • CONNECTOR, Strain Relief
103148 54” • CABLE, Welding #4 Ga
143672 1 ASSEMBLY, Cable (Battery to Battery Charger) (If equipped with Inline Fuse)
105534 1 • PLUG, Battery Connector 175 Amp 2-prong
103148 81” • CABLE, Welding #4 Ga
12 126076 1 ASSEMBLY, Connector Cable (from Motor & Main Disconnect Switch)
105534 1 • PLUG, Battery Connector 175 Amp 2-prong
103148 80” • CABLE, Welding #4 Ga
Part list continued on the next page.
Index
No.
Skyjack
Part No.
DescriptionQty.
Figure 6.5-2. Battery Tray Assembly - ANSI/CSA (EE Rated)
AH
