SECTION 6, Page 109
SJIII Series - The Conventionals 129919
Figure 6.6-3. Electrical Panel Assembly (CE)
Index
No.
Skyjack
Part No.
DescriptionQty.
A 130888 1 ASSEMBLY, Electrical Panel (CE )
1 130579 1 • WELDMENT, Control panel
112495 4 • • BOLT, Hex Hd 1/4”-20 x 3/8” Gr. 5
2 132794 1 • CLAMP, Plastic cable
3 125893 1 • BUMPER, Rubber Female
103892 1 • BOLT, Hex head 1/4”-20 x 5/8” Gr. 5
103995 1 • WASHER, Flat 1/4”
104000 1 • WASHER, Lock 1/4”
103980 1 • NUT, Hex 1/4”-20
4 103101 1 • CONTACTOR, Solenoid (SPNO)
5 103336 1 • HOURMETER
6 117325 2 • BREAKER, Circuit 15 Amp
7 129182 1 • RESISTOR, Prop. speed 30 Ohms 25 Watt (Model 32XX/46XX)
130892 1 • RESISTOR, Prop. speed 40 Ohms 25 Watt (Model 3220 with Power Deck)
116066 2 • SCREW, Round head machine #4-40 x 1/2”
116068 2 • WASHER, Lock #4
116067 2 • NUT, Hex #4-40
8 108589 6 • RELAY, 24V sealed
9 116711 2 • SPACER, Relay Stand-off
10 119758 1 • MODULE, Encapsulated Diode
11 103011 2 • BLOCK, Terminal 12P
103956 6 • SCREW, Round head #6-32 x 1.0”
103985 6 • NUT, Hex head #6-32
12 130149 1 • HARNESS, Ground “02”
13 103962 3 • SCREW, Round head machine #10-32 x 1/2”
14 104003 6 • NUT, Hex head #10-32
15 104185 5 • WASHER, Lock #10
16 104694 3 • WASHER, Flat #10
17 104546 2 • SCREW, Round head #10-32 x 2.0”
18 105621 1 • SCREW, Round head #10-32 x 1.0”
To Next Page
