SECTION 6, Page 115
SJIII Series - The Conventionals 129919
Figure 6.7-1. 24VDC Inverter
A 128769 - INVERTER, 24VDC - 120VAC @ 60 Hz (ANSI/CSA)
B 128770 - INVERTER, 24VDC - 110/220VAC @ 50 Hz (CE)
C 135990 - INVERTER, 24VDC - 120VAC @ 60 Hz (ANSI/CSA)
D 135991 - INVERTER, 24VDC - 110/220VAC @ 50 Hz (CE)
1 132494 1 RELAY, Inverter Timer Cut-Off (If equipped)
137417 1 RELAY, Inverter Timer Cut-Off (If equipped)
(Refer to Section 3 for Serial No. Breakdown chart)
2 103999 2 WASHER, Lock 3/8 nom
3 104606 2 NUT, Lock Hex 3/8-16 grade B
4 103473 2 BOLT, Hex Head, 3/8-16 x 1.00 grade 5, (CE)
103952 2 BOLT, Flat Head, 3/8-16 x 1.00 grade 5, (Model 32XX & 46XX) (ANSI/CSA)
5 103855 4 BOLT, Hex Head, 1/4-20 x 1/2 grade 5
6 104000 4 WASHER, 1/4” Lock Washer
7 119007 2 MACHINE SCREW, Flat Head 82 1/4-20 x 5/8
8 119061 1 FUSE BOX, C/W Cover
9 103364 1 CONNECTOR, 50 amp A, B
10 129145 1 SUPPORT, Inverter
11 103068 2 INSULATOR, Fuse
12 146442 1 FUSE, 100 AMP
13 112495 2 BOLT, Hex Head 1/4-20 x 3/8 grade 5
14 129187 1 CABLE, 4 GA, 1/4”, 21 5/16 (+,+) A, B
15 129157 1 CONNECTOR ASSY, 50 AMP, Grey (24VDC Inverter) A, B
16 103955 2 MACHINE SCREW, RND HD 6-32 x 3/4 A, B
17 146454 1 LABEL, Inverter Fuse (100A)
18 133867 1 CABLE, 4 GA, 1/4”, 25 5/16 (+,+) C, D
19 103858 1 BOLT, Hex head 1/4” - 20 x 1-1/4” grade 5
20 115649 1 NUT, Lock hex 1/4” - 20
21 108791 3 CLIP, Cable C, D
22 108503 1 CONNECTOR C, D
Index
No.
Skyjack
Part No.
DescriptionQty.
