SECTION 6, Page 121
SJIII Series - The Conventionals 129919
Figure 6.8-2 Labels - Operators Control Box
- (Ref.) - (To order a complete label kit, refer to Figure 6.8-1)
*1 130434 1 LABEL, Lift/Drive Direction
*2 130637 1 LABEL, Base/Off/Platform (ANSI/CSA Models)
130617 1 LABEL, Base/Off/Platform (CE Models)
*3 111814 1 LABEL, Emergency Stop
*4 118711 2 LABEL, “Hydraulic Proportional”
*5 130638 1 LABEL, Lift/Off/Drive
*6 116577 1 LABEL, Torque Normal/High
*7 124199 1 LABEL, Joystick Controller
*8 105352 1 LABEL, Horn
9 130639 1 LABEL, Overload (CE )
*Included in the label kit
NOTE: Supply Model Number, Serial Number, Country and Language
when ordering complete machine labels.
1
Index
No.
Skyjack
Part No.
DescriptionQty.
10990AB
8
7
4
3
2
6
5
9
NOTE: CE Model Shown
