SECTION 3, Page 27SJIII Series - The Conventionals 129919
Figure 3.4-3b. Electrical Panel Diagram - ANSI/CSA EE Rated Models (No Options)
A B C D E F G H
M125718AG
V
Z
Y
X
W
AI
Figure 3.4-3a
Refer to following page(s) to locate model,
serial number and respective diagram
Serial Breakdown Reference Chart
Model Serial Number
3220 60000967 & Above
3226 27002840 & Above
46XX 70003078 & Above
To Next Page
