Skyjack 4632 - Page 84

SECTION 5, Page 5
SJIII Series - The Conventionals 129919
Table 5-2. Torque Specifications
Directional valve mounting bolts
28-32 lbf.in 2.16 – 3.61 Nm
Wheel mounting bolts
90 lbf.ft 122.02 Nm
Wheel motor castle nut
200 lbf.ft 271.20 Nm
Parking brake cylinder rod nut
35 lbf.ft 47.46 Nm
Cartridge
Size
Torque
08 38 58 10 12 16
Lbf.ft (max)
20 20 20 25 35 50
Lbf.in (max)
240 240 240 300 420 600
Nm (max)
27.12 27.12 27.12 33.90 47.46 67.80
Coils
Size
Torque
All coils
Lbf.ft (max)
4 to 5
Lbf.in (max)
48 to 60
Nm (max)
5.42 to 6.78
SAE Plugs
Size
Torque
2 4 5 6 8 10 12 16
Lbf.ft (max)
3 10 15 15 25 25 30 35
Lbf.in (max)
36 120 180 180 300 300 360 420
Nm (max)
4.07 13.56 20.34 20.34 33.90 33.90 40.68 47.46
Newton-meter = Nm Pound-force foot = lbf.ft Pound-force inch = lbf.in
60056AC
