Skyjack SJ45 AJ+ Service Manual

42
238274AAA SJ45 AJ+
Section 2 – Maintenance Tables and Diagrams MEWP Specifications
2148AA
Height &
Reach
Working Height - maximum 15.54 m 51 ft 0 in
Platform Height - maximum 13.72 m 45 ft 0 in
Horizontal Reach - maximum 6.93 m 22 ft 9 in
Horizontal Reach - at maximum height 2.98 m 9 ft 10 in
Horizontal Reach - fly boom retracted 5.23 m 17 ft 2 in
Tailswing 0.61 m 2 ft 0 in
Up and Over Clearance - at platform 7.53 m 24 ft 8.75 in
Up and Over Clearance - at main boom 7.45 m 24 ft 5.25 in
Platform
Platform Size
0.76 x 1.52 m 30 x 60 in
0.76 x 1.83 m 30 x 72 in
Platform Rotation 175°
Platform rotation radius 1.14 m 45 in
Platform height - stowed 0.28 m 11 in
Overall railing height 1.35 m 53 in
Platform railing height 1.11 m 44 in
Jib
Jib Length 1.42 m 55.75 in
Jib vertical Range of Motion 2.7 m 106.5 in
Jib Range of Motion - down 70°
Jib Range of Motion - up 75°
Dimensional
Data
Height - stowed min. 2.06 m 6 ft 9 in
Stowed length @ min. height 6 m 19 ft 8 in
Stowed length - min. 4.75 m 15 ft 7 in
Width 2.29 m 7 ft 6 in
Wheelbase 2.03 m 6 ft 8 in
Ground Clearance - chassis 0.39 m 15.25 in
Ground Clearance - front axle 0.33 m 13 in
Axle Oscillation 0.09 m 3.7 in
Turning Radius - inside 1.5 m 4 ft 11.25 in
Turning Radius - outside 4.34 m 14 ft 3 in
Turret Rotation 360°
114
2.11 MEWP Specifications
To order go to Discount-Equipment.com

Skyjack SJ45 AJ+ Specifications

General
