Section 3 - Operation Diagrams
Diagram 3.5 Axle Oscillation Diagrams
WARNING
Do not raise the platform in work mode if it is not on a rm level surface.
Axle oscillation free (travel mode) - drive speed 4.5 mph (7.2 km/h) max.
Axle oscillation locked (work mode) - drive speed 0.5 mph (0.8 km/h) max.
Figure 3-28. Axle Oscillation - SJ 40T/61T
Axle oscillation free (travel mode) - drive speed 4.5 mph (7.2 km/h) max.
Axle oscillation locked (work mode) - drive speed 0.5 mph (0.8 km/h) max.
Figure 3-29. Axle Oscillation - SJ 45T/66T
SJ 40T & SJ 45T
SJ 61T & SJ 66T
