Technical diagrams Section 7 – Technical Diagrams and Specifications
Dimensions - SJ40 T+ (continued)
A
B C
E
D
2.44 m/1.83 m
[96 in/72 in]
170°
A 0.91 m
[36 in]
1.62 m
[64 in]
C 1.12m
[3 ft 8 in]
B 2.29 m
[7 ft 6 in]
2.24 m
[7 ft 6 in]
360°
5.18 m
[17 ft ]
D 0.27 m
E 0.04 m
