Skyjack SJKB-33N - Tire Specifications and Operating Times; Tire Models and Fill Specifications

SECTION 1 INTRODUCTION
PURPOSE OF EQUIPMENT ................................................................................................................................ 1
USE OF EQUIPMENT........................................................................................................................................... 1
WARNINGS........................................................................................................................................................... 1
DESCRIPTION...................................................................................................................................................... 1
SPECIFICATIONS AND FEATURES..................................................................................................................... 3
WORK PLATFORM MAJOR COMPONENT IDENTIFICATION (SJKB-33N) ........................................................ 4
WORK PLATFORM MAJOR COMPONENT IDENTIFICATION (SJKB-33i, 33C, 40i, 40C) .................................. 5
SECTION 2 OPERATION
OPERATOR QUALIFICATIONS ............................................................................................................................ 1
OPERATOR RESPONSIBILITY FOR MAINTENANCE......................................................................................... 1
MAINTENANCE AND INSPECTION SCHEDULE................................................................................................. 1
OWNER’S ANNUAL INSPECTION RECORD ....................................................................................................... 1
GENERAL MAINTENANCE HINTS....................................................................................................................... 1
OPERATING CONTROL IDENTIFICATION .......................................................................................................... 1
Base Controls - Electrical ...................................................................................................................................... 2
Base Controls - Mechanical................................................................................................................................... 3
Base Controls - Hydraulic ...................................................................................................................................... 4
Platform Controls - Electrical ................................................................................................................................. 6
OPERATING PROCEDURES ............................................................................................................................... 7
Prestart Checks ..................................................................................................................................................... 8
Start and Operation ............................................................................................................................................... 8
Shutdown Procedure ............................................................................................................................................. 9
Loading and Tie Down Procedure.......................................................................................................................... 9
BATTERY SERVICE AND CHARGING PROCEDURES ....................................................................................... 10
Battery Service ...................................................................................................................................................... 10
Battery Charger Procedures .................................................................................................................................. 10
BATTERY CHARGER OPERATION ..................................................................................................................... 11
BRAKE OPERATION TEST PROCEDURE .......................................................................................................... 13
LIST OF TABLES
TABLE 2-1. MAINTENANCE SCHEDULE............................................................................................................ 12
TABLE 2-2. OWNERS ANNUAL INSPECTION RECORD.................................................................................... 13
TABLE 2-3. TIRE SPECIFICATIONS (SJKB-33N) ............................................................................................... 13
TABLE 2-4. MAXIMUM PLATFORM CAPACITIES............................................................................................... 13
TABLE 2-5. GENERAL SPECIFICATIONS (SJKB-33N) ....................................................................................... 14
TABLE 2-6. TIRE SPECIFICATIONS (SJKB-33i, 33C, 40i, 40C).......................................................................... 15
TABLE 2-7. STANDARD OPERATING TIMES (SJKB-33N, 33i, 33C, 40i, 40C) ................................................... 15
TABLE 2-8. GENERAL SPECIFICATIONS (SJKB-33i, 33C, 40i, 40C)................................................................. 16
Page i
TABLE OF CONTENTS
SECTION 2, Page 18
SJKB Battery Powered
Table 2-6. Tire Specifications - SJKB-33i, 33C and SJKB-40i, 40C
Mtwb203
FUNCTION TEST SECONDS
Riser Up 32-36
Riser Down 24-26
Boom Up 16-18
Boom Down 24-26
Boom Extract (SJKB 33N, 33i, 33C) 19-23
Boom Retract (SJKB 33N, 33i, 33C) 14-16
Boom Extract (SJKB 40i, 40C) 30-34
Boom Retract (SJKB 40i, 40C) 20-22
Jib Up 12-14
Jib Down 10-12
Platform Rotate Left 7-9
Platform Rotate Right 7-9
Turret Rotate Clockwise 57-63
Turret Rotate Counter Clockwise 57-63
Table 2-7. Standard Operating Times - SJKB-33N and SJKB-33i, 33C and SJKB-40i, 40C
Mtwb207
Model
Tire Fill Specification
Size Rating Type Pressure
SJKB-33C, 40C 10 x 16.5 10 Ply Air 55 PSI
SJKB-33i, 40i 11 L 16SL 12 Ply Air 55 PSI
SJKB-33C, 40C
(Lugged Flotation)
31 x 15.5 x 15 8 Ply Air 55 PSI
SJKB-33i, 40i
(Ribbed Flotation)
31 x 13.5 x 15 8 Ply Air 55 PSI
SJKB-33C, 40C
(Lugged Foam
Filled)
10 x 16.5 10 Ply Solid Urethane *
SJKB-33i, 40i
(Ribbed Foam
Filled)
11 L 16SL 12 Ply Solid Urethane *
HIGH FLOTATION
(Ribbed)
31 x 13.5 x 15 8 PLY Solid Urethane *
* 28 Durometer Fill installed at 55 psi.
