SECTION 1, Page 3SJKB Battery Powered
TABLE 1-1. SPECIFICATIONS AND FEATURES
Specifications
WEIGHT (SJKB-33N) ........................................................................................14,500# (6577kg)
WEIGHT (SJKB-33i, -33C)..................................................................................9,700# (3946kg)
WEIGHT (SJKB-40i, -40C) ................................................................................12,800# (5806kg)
WORK HEIGHT (SJKB-33N) .................................................................................... 39' (11.89m)
WORK HEIGHT (nominal)(SJKB-33i, -33C) ............................................................. 39' (11.89m)
WORK HEIGHT (nominal)(SJKB-40i, -40C) ............................................................. 46' (14.02m)
RAISED PLATFORM HEIGHT(nominal)(SJKB-33N) ...............................................33' (10.06m)
RAISED PLATFORM HEIGHT (nominal)(SJKB-33i, -33C) ...................................... 33' (10.06m)
RAISED PLATFORM HEIGHT (nominal)(SJKB-40i, -40C)....................................... 40' (12.19m)
STOWED HEIGHT ......................................................................................................6' 7" (2.0m)
OVERALL WIDTH (SJKB-33N) ................................................................................. 48" (1.22m)
OVERALL WIDTH (SJKB-33i, -40i) ..........................................................................5' 9" (1.75m)
OVERALL WIDTH (SJKB-33C,-40C)......................................................................5' 10" (1.78m)
STOWED LENGTH (SJKB-33N).............................................................................14' 4" (4.36m)
STOWED LENGTH (SJKB-33i, -33C) .....................................................................15' 2" (4.62m)
STOWED LENGTH (SJKB-40i, -40C) .....................................................................18' 3" (5.56m)
PLATFORM CAPACITY (Unrestricted) .................................................................... 500# (227kg)
PLATFORM SIZE (SJKB-33N,-33i,-40i).......................................30.00" x 48.00" (.76m x 1.22m)
PLATFORM SIZE (SJKB-33C, -40C)............................................ 30.00 x 66.00" (.76m x 1.68m)
ELECTRICAL SYSTEM ............................................................................................. 48 Volts DC
GRADABILITY .......................................................................................................................30%
TURRET ROTATION (SJKB-33N) ............................................................ 355° (Non-continuous)
TURRET ROTATION (SJKB-33i,-33C,-40i,-40C)...................................... 365° (Non-continuous)
TIRE SIZE (SJKB-33N) ............................................................. 27.5" x 7.5" x 15" Solid Urethane
TIRE SIZE (SJKB-33i, -40i) (Ribbed) ............................................................. 11 L 16SL Air Filled
TIRE SIZE (SJKB-33C, -40C) (Lugged) ................................................ 30" x 10" x 16.5 Air Filled
Features
STANDARD EQUIPMENT
4 Foot Hydraulically Controlled Boom Jib
Variable Speed Drive and Function Controls
In-Line Elevating Assembly
Continuous Drive and Steer Directional Sensing
Electrical Dynamic Braking System
Two Spring-Applied Hydraulically-
Released Parking Brakes
ANSI and CSA Standards Compliance
OPTIONAL EQUIPMENT
Operator Horn
All Function Motion Alarm
Descent Alarm
Travel Alarm
Flashing Amber Light
Spring-Loaded Half Gate
Spring Loaded Full Gate
On-Board 110VAC Generator
Lifting Lugs
Non Marking Tires
Additional Battery Boxes
Overload Sensing (France)
30" x 66" Platform (SJKB-33i, 40i Only)
High speed drive (SJKB-33i, 40i Only)
High Flotation Tires (SJKB-33C, 40C Only)
SECTION 2, Page 12
SJKB Battery Powered
Table 2-1. Maintenance and Inspection Schedule
Daily Weekly Monthly 3 Months 6 Months *Yearly
MECHANICAL
Struct. damage/welds (1)
á á
Parking brakes (2)
á á
Tires and wheels (1)(2)(3)
á á
Guides and slides (1)(2)
á á
Railings and gates (2)(3)
áá
Bolts and fasteners (3)
á á
Rust (1)
áá
Wheel bearings (2) and king pins (1)(6)
áá
Turret gear (1)(2)(3)(6)
áá
Turret gear box (1)(2)(3)
áá
Pivot pins (1)
á á
Steer cylinder ends (6)
áá
Axle gear oil (12)
á
ELECTRICAL
Battery fluid level (1)
á á
Control switches (1)(2)(3)
á á
Cords and wiring (1)
á á
Battery trays (11)
áá
Battery terminals (1)(3)(11)
á á
Terminals and plugs (1)(3)(11)
á á
Generator and recepticals (2)
á á
Limit switches (2)
á á
Tilt sensor (2)
á á
Directional sensing (2)
á á
HYDRAULIC
Hydraulic fluid level (1)
á á
Hydraulic leaks/hoses (1)(3)
á á
Lift/lowering time (8)
áá
Hydraulic cylinders (1)(2)(3)
áá
Emergency lowering (2)
á á
Lift capacity (5)
áá
Hydraulic oil filter (7)
áá
MISCELLANEOUS
Labels (1)(9) Manuals (10)
á á
NOTES:
(1) Visuallly inspect (2) Check operation
(3) Check tightness (4) Check oil level
(5) Check releif valve setting. Refer to Serial Number Nameplate.
(6) Lubricate (7) Replace
(8) See Table 2-5. General Specifications.
(9) Replace if missing or illegible.
(10) Proper Operation Manual MUST be in manual
enclosure. (11) Clean
(12) Change oil. *Record inspection date.
MT33N202
