SJKB-40-D, SJKB-40-D/FSECTION 3, Page 18
JUN. 1999
FIGURE 3-8/ FIGURE 3-9./FIGURE 3-10./FIGURE 3-11./ FIGURE 3-12. ELECTRICAL SCHEMATIC PARTS LIST
1 2 3 4 5 6 7
Ref.
No.
Skyjack
Part No.
Description
Units
per
Assy
1 2 3 4 5 6 7
Ref.
No.
Skyjack
Part No.
Description
Units
per
Assy
01CR
THRU 701943 RELAY, 12 Volt sealed AR
74CR
108CR 300242 CONTACTOR, Emergency pump 1
114CR 701943 RELAY, 12 Volt sealed 1
2G-56 111626 LOCKOFF, Gasoline 1
2H-12 707825 FLOW CONTROL VALVE, Proportional 1
2H-21A 707820 VALVE COIL, Dump 1
2H-59 708331 VALVE COIL, High speed drive 1
2P-50 111618 LOCKOFF, Propane 1
3H-26B 703803 VALVE COIL, Brake 1
2H-28B 703803 VALVE COIL, 5° Tilt brake 1
4H-13A 707821 VALVE COIL, Riser down 1
4H-14A 707821 VALVE COIL, Riser up 1
4H-15 $ REVERSE DRIVE VALVE 1
4H-16 $ FORWARD DRIVE VALVE 1
4H-23A 707821 VALVE COIL, Right steer 1
4H-24A 707821 VAVLE COIL, Left steer 1
4H-30A
THRU 707821 VALVE COIL , Directional 12
4H-41
B1 103295 BATTERY, 12 Volt 675CCA 1
BCB1 707678 Governor control (Kubota engine) 1
701643 Governor control (Ford engine) 1
BFC 704332 CONTROL BOARD, Boom function 1
BP20A 707912 ALARM, Boom motion (option) 1
BP27 103057 BEEPER, Tilt alarm 1
BP46 707912 ALARM, All motion (option) 1
BP58A 707912 ALARM, Boom descent (option) 1
BP-26A 707912 ALARM, Travel (option) 1
CB1 702402 CIRCUIT BREAKER 1
D08
THRU 102921 DIODE, 6 Amp/ 1000 PIV AR
D114
DS1 102600 DISCONNECT SWITCH, Battery 1
EDA1 701547 CONTROLLER BOARD 1
F1 114866 FUSE, 250 Volt/1 amp 1
FG1 706282 GUAGE, Fuel level 1
FG1-1 706172 SENDING UNIT, Fuel guage 1
FL-20A 703323 LIGHT ASSEMBLY, Flashing (option) 1
FP1 115304 FUEL PUMP, Electric (Kubota engine) 1
115387 FUEL PUMP, Electric (Ford engine) 1
H1 703322 HORN, (Option) 1
LA1 707675 THROTTLE ACTUATOR, Linear (diesel) 1
707677 THROTTLE ACTUATOR, Linear (gas and dual fuel) 1
CS1 707676 CHOKE ACTUATOR, Linear (gas and dual fuel only)(Kubota engine) 1
LB1-LB3 (Ref.) LIGHT ASSEMBLY, Indicator 3
103202 • LIGHT HEAD 1
102671 • LIGHT BASE 1
703185 • • BULB 1
LB4 703720 INDICATOR LIGHT, Amber (diesel only) 1
LS1 702434 LIMIT SWITCH, Riser lift 1
LS2 700160 LIMIT SWITCH, Boom telescope 1
MDSD1 701546 DUAL SOLENOID DRIVER BOARD 1
OPS1 112838 PRESSURE SENSOR, Oil (Kubota engine) 1
R1 707177 SPEED CONTROL SWITCH, Boom function 1
S1-S2 (Ref.) SWITCH ASSEMBLY, Emergency stop 2
102769 • SWITCH HEAD, Emergency stop 1
103281 • CONTACT BASE, NC switch 1
S3 (Ref.) SWITCH ASSEMBLY, Key 1
102753 • HEAD, Key switch 1
104466 • Key, #455 1
103279 • BASE, Contact 2 N.C. 1
103141 • CONTACT, N.O. 1
S4-S5 701929 TOGGLE SWITCH, 2 Position momentary SPDT 2
S6-S7 701931 IGNITION SWITCH 2
S8-S9 701929 TOGGLE SWITCH, 2 Position momentary SPDT 2
S10 701930 TOGGLE SWITCH, 2 Position maintained SPDT 1
S11 700187 FOOT SWITCH 1
S12 704330 CONTROLLER, Drive/steer (without horn) 1
707658 CONTROLLER, Drive/steer (with horn) 1
S14-S18 702662 TOGGLE SWITCH, 3 Position momentary DPDT 3
S19-S27 102853 TOGGLE SWITCH, 3 Position momentary SPDT 11
S28 706294 LIMIT SWITCH, Turret directional sensing (booted) 1
S29 701930 TOGGLE SWITCH, 2 Position maintained SPDT 1
TP1 707824 TACHOMETER SENSOR (Kubota engine) 1
115389 TACHOMETER SENSOR (Ford engine) 1
TPS1 113400 TEMPERATURE SENSOR (Kubota engine) 1
TS1 700552 TILT SWITCH 1
TT1 701925 HOUR METER 1
VM1 704732 VOLT METER 1
VS1 111623 VACUUM SWITCH (Kubota dual fuel) 1
TD1 704616 RELAY, Time delay (Ford engine) 1
708685 CABLE ASSEMBLY, Starter to disconnect 1
708686 CABE ASSEMBLY, E-Pump to disconnect 1
707230 CABE ASSEMBLY, Battery to chassis 1
706524 CABE ASSEMBLY, Battery to disconnect 1
707230 CABE ASSEMBLY, Engine block to chassis 1
706096 CABE ASSEMBLY, E-Pump relay to E-pump 1
709554 CABE ASSEMBLY, Starter to alternator 1
