Skytrac DSAT-300 Series Battery Replacement Instructions

SkyTrac Systems Ltd.
Document Revision 01.000 DOC0595 Page 7 of 21
Restricted Proprietary and Confidential Information
6. Slip the battery connectors under the battery cross bar where there is no heat shrink
(mid region) and remove the batteries as shown in Figure 7 .
Figure 7 – Battery Removal
7. Take one of the replacement batteries and bend the cable around the front face to
the right as shown in Figure 8 .
Figure 8 – Battery Cable Bend
