DSAT-300 USER GUIDE 18
Document Rev. 1.015 DOC0594 Page 18 of 28
Restricted Proprietary and Confidential Information
DSAT-300I with Parani SD200 fitted
Notes:
The DSAT-300 can only communicate with a single mobile device at one time
The DSAT-300 will not transition into sleep mode if the Bluetooth / Wi-Fi device is active
If email communication is not required the Bluetooth / Wi-Fi device should be disconnected to extend battery
operating time
Bluetooth adapters receive power directly from the DSAT-300 RS232(DB9) port (after approx. 1 minute)
unless the charge level is too low
Wi-Fi adapters do not receive power from the DSAT-300 RS232(DB9) port and require external power to
function.
See STS-RDA User Guide (DOC 1101) for connection and menu information.
13 ANTENNAS
13.1 EXTERNAL ANTENNA INSTALL
As already stated, the DSAT-300I has an integrated antenna. The DSAT-300E can use ether a portable active L1
GPS antenna STS0039 and a separate portable passive Iridium antenna STS0040 or a single TSO Combination
Antenna STS0021:
Top Bottom
