6 MOUNTING THE RESERVE PARACHUTE
The RANGE X-ALPS can be combined with most compact reserve parachutes available
in the market. The initial installation should be carried out by a certified compatibili-
ty checker who will verify that your reserve parachute deploys properly and will certify its
compatibility in the reserve’s packing certificate. It is important for the pilot to perform
the test deployment of the reserve parachute himself while sitting in the harness in a
simulator because the results of the test are affected by body size and strength. Before
installation, ensure that the rescue parachute has been packed recently. The pack interval
is normally every six months, but verify this by reading the information in the user manu-
al of the rescue parachute.
CONNECTING THE RESERVE CHUTE TO THE HARNESS
1. Connect the rescue handle with the inner container of your rescue chute. Use the loop
in the middle of your inner container.
2. Connect the V-line of the RANGE X-ALPS to the connection line of your rescue system.
To connect the reserve chute to the V-line, you must use a screw shackle with at least
2400 daN strength. The lines have to be connected on both sides of the screw shackle
and must be secured with rubber bands by means of Larks Head knot (pic 1).
As an alternative, you can connect the two lines with softlinks if the size of the loop
on the reserve chute allows this (pic 2).
3. Pack your rescue system into the front container of the RANGE X-ALPS. If you are
uncertain, you should consult a specialist or contact your local skywalk dealer.
EN
1
2
