Skywalker ActivPlay SJG208 - Part Identification

4
Before you begin, take a look at the drawings below to make sure you have all the parts. The numbers in the squares
to the left (key numbers) will help you identify the parts during assembly.
PART IDENTIFICATION
1 2
3
4
5
6
7
8
Upright Pole (x2)
U Tube (x1)
Connection
Frame (x1)
Swing Chain
(x4)
Swing Frame
Tube (x4)
Foam (x4)
(pre-installed)
9
Blue Plastic
Sleeve (x2)
10
Inner Cap (x2)
(pre-installed)
11
M8X65mm Button
Bolt (x4)
12
M8 Locknut (x2)
Top Frame 1 (x1) Top Frame 2 (x1)
