Skywalker APB60SF09 - Part Identification

4
Before you begin, take a look at the drawings below to make sure you have all the parts! The numbers in the squares
to the left (key numbers) will help you identify the parts during assembly.
PART IDENTIFICATION
1 2
3
4
5
6
7
8 9
10
11
12
Frame Tube (x6) Leg (x6)
Enclosure Tube
(x6)
Rail (x6)
Joint (x6)
Mat with Net (x1)
Pad with Net (x1)
Elastic with Ball (x36)
Upper Foam 21.5”
(545 mm) (x6)
Middle Foam 11.9”
(302 mm) (x6)
Lower Foam 8” (205
mm) (x6)
Rail Foam 23.4” (595 mm)
(x6)
