10
STEP 7
Pad with Net (x1)
5
ASSEMBLY
Fasten the net to the bottom of each leg using the self-tapping screws (10).
STEP 8
Self-tapping Screw (x6)
10
At this point the frame may not lay flat on the ground... but don’t freak out!
The frame will straighten out with further assembly. Lay the pad with net
(5) on the frame. Adjust the position of the pad so that the slits are directly
above the legs. Insert the top of the legs into the slits in the pad. Note: It
might be a good idea to place the seam of the net opposite of the enclosure
door.
(10)
(10)
(10)
(10)
