18
STEP 21
Using a ladder, tie one end of the tightening cord (21) to a pole cap. Pull the
cord tight, and then attach the other end of the cord to the nearest pole cap.
Now attach the 4 straps at the top of the backboard to the tightening cord,
and tie knots to secure. Thread the 2 straps on the back of the backboard
through the enclosure net and tie knots to secure. If any cord is left over, tie
another knot 6 inches below the pole cap and cut off the excess.
Tightening Cord (White) (x1)
21
(21)
!
Starting from the enclosure door, lift one of the assembled poles and insert the straight tube (9) into the
socket. Repeat this process to assemble the 5 remaining poles.
Helpful tip: When inserting the enclosure poles, pull back on the middle of the poles!
STEP 22
ASSEMBLY
Socket
Socket
Pull back
To Next Page
