ASSEMBLY
14
Place four silver springs in the middle of one curved tube. To make sure
the V-rings and frame holes line up properly, count the number of frame
holes starting from the corner and moving towards the middle curved tube.
Then, count the V-rings starting from the same corner to the exact number
of spring holes and place the springs. Repeat this step on each side to
place a total of 16 additional springs.
Next, attach four additional gold springs on each side of the frame by
placing them on either side of the sockets.
You should now have attached 16 more gold springs (four on each side).
STEP 13
11
Silver Spring (x16)
STEP 14
10
White springs
Gold Spring (x16)
