Wireless
The FPV Google with Built-in 5.8Ghz Diversity Receiver and diversity Antenna inputs for best reception. It working in
diversity mode to achieve good signal utilization and improve the image quality.
It supports 4 Bands and total 32channels (Bands selection and Resulting Frequencies see details in Specifications
）
））
）
Bands Setup
·
Long Press Button "BAND" to enter Bands setup (beeps indicating the current band) and press the Button "Band"
again within 3 seconds to select the Bands. Different beeps refer to different Bands.
·
It'll return to normal working mode after 1 short beep if there is no operation within 3 seconds.
·
Beep Receiver BAND
1 short beep Band 1
2 short beep Band 2
3 short beep Band 3
4 short beep Band 4
Channel Setup
To Next Page
