SkyZone SKY03 - Specifications

9

Specifications
Binocular
Display
FOV 43 degrees (Diagonal)
Resolution 800X600(SVGA), 1,440,000 color sub-pixels
Brightness
200cd/㎡
Interpupillary
distance (IPD)
57.5 to 69.5mm Adjustable
3D Display Side-by-Side(half)
Wireless
Receiver
ISM 5.8GHz 48 Channel, Diversity receiver.
Band CH 1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
A 5865M 5845M 5825M 5805M 5785M 5765M 5745M 5725M
B 5733M 5752M 5771M 5790M 5809M 5828M 5847M 5866M
E 5705M 5685M 5665M 5645M 5885M 5905M 5925M 5945M
F 5740M 5760M 5780M 5800M 5820M 5840M 5860M 5880M
R 5658M 5695M 5732M 5769M 5806M 5843M 5880M 5917M
L 5362M 5399M 5436M 5473M 5510M 5547M 5584M 5621M
Sensitivity -90dBm±1dBm
Antenna port 2 X SMA,50ohm
Front Camera
FOV 60 degrees (Diagonal)
Resolution 640X480(VGA)
Focal length f=4.0mm
F/NO F/NO=2.8
Head Tracker
Sensor 3-axis Accelerometer, 3-axis gyroscope
Output PPM 8 channel, Optional 5-6CH,5-7CH,5-8CH,6-7CH,6-8CH,7-8CH
Record
Micro SD Support to 128GB (UHS-I Interface,U1)
Compression H264, 30fps,MOV
Data rate 6Mbps
AV Signal
Video Standard NTSC/PAL
Video output level 1.0Vp-p Typ. / 75ohm
Audio output level 1.0Vp-p Typ. / 10Kohm
AV Port
AV OUT(3.5mm4P) Diversity receiver, Video, Audio output
EAR OUT(3.5mm3P) Stereo 16Ω/150mW
AV IN(3.5mm4P) Video, Audio input
HDMI IN(C-Type) HDMI 1.4 specification: 1920x1080p60, 1920x1080p50,
1920x1080i60, 1920x1080i50,1280x720p60, 1280x720p50, 576p,
576i, 480p, 480i, PC Format(Not all)
Power Supply
DC IN
DC 7～26V/ 1A
Power Consumption 12V input: 5.8W (RF mode)
Dimensions 170(L)X83(W)X44(H)mm (Not include prominent part)
Weight 231g (Not include package box)
Operating Temperature
0℃～+60℃
