OPERATION
35
The display will show:
models 2925 and 2935
C O N T . M X 0 . 0 s
- . --K V A C --. --mA
model 2945
W - C O N T M X 0 . 0 s
- . --K V A C --. --mA
If you are not performing a Ground Continuity Check, the Ground Continuity must be set
to the “OFF” (Disabled) position. It is not necessary to connect the “Cont.Check” cable
since this test will not be performed if the circuit is disabled. The instrument will proceed
with the Hipot Test when the “Test” switch is activated.
4. To initiate a test, press the TEST switch on the front panel. The red High Voltage
Arrow indicator will flash and the display will immediately show:
models 2925 and 2935
R a m p MX XXX . X s
X . XX K V A C XX . XX mA
or
D w e l l MX XXX . X s
X . XX K V A C XX . XX mA
model 2945
W - R a m p MX XXX . X s
X . XX K V A C XX . XX mA
or
W- T e s t MX XXX . X s
X . XX K V A C XX . XX mA
The instrument will continue to output the desired voltage for the duration of the selected
dwell time for model or selected Ramp and Dwell times on model 2925, 2935, and 2945.
