SPECIFICATIONS
14
Descriptions
Specifications
High Resistance Limit
Range:
0 - 1000 M (0 = Off)
Low Resistance Limit
Range:
1 - 1000 M
Delay Timer
Range:
0, 0.5 - 999.9 sec (0 = Constant)
Resolution:
0.1 sec/step
Accuracy:
 (0.1% + 0.05 sec)
GENERAL
REMOTE CONTROL
AND SIGNAL
OUTPUT
The following input and output signals are provided through
the 9 pin D type connector;
1. Remote control : test and reset
2. Outputs : pass, fail and test in process
PROGRAM MEMORY
5 Sets (2925, 2935, and 2945)
SECURITY
Key Lock capability to avoid unauthorized access to all test
parameters. Memory Lock capability to avoid unauthorized
access to memory locations.
LINE CORD
Detachable 7 ft. (2.13m) power cable terminated in a three-
prong grounding plug.
TERMINATIONS
5ft.(1.52m) high voltage and return leads (2) with clips. An
optional remote receptacle box may be purchased for testing
items terminated with a line cord. International receptacles are
also available.
MECHANICAL
Tilt up front feet.
Dimensions: (W x H x D) 11 x 3.5 x 14.56 in. (280 x 89 x 370 mm)
Weight: 20 lbs (9 Kgs)
ENVIRONMENTAL
Operating Temperature : 32 - 113F (0 - 45C)
Relative Humidity - 0 to 95%
CALIBRATION
Traceable to National Institute of Standards and Technology
(NIST). Calibration controlled by software. Adjustments are
made through front panel keypad in a restricted access
calibration mode. Calibration information stored in non-
volatile memory.
