OPERATION
OPERATION INSTRUCTIONS FOR
Models 2925, 2935, and 2945
A. POWER UP:
Check to be sure the correct input line voltage has been selected on the
rear panel. Either 115 volts AC or 230 volts AC. Connect the power
input plug into its socket on the rear panel of the instrument. Connect the male end of the
plug to the outlet receptacle.
Please be sure that the safety ground on the power line cord is not defeated and that you
are connecting to a grounded power source. Also, connect the rear panel chassis ground
for additional safety.
Turn on the POWER switch located on the lower left hand side of the front panel. Upon
powering the instrument up, a POWER ON SELF TEST (POST) will be automatically
performed. This test will check for the condition of the ram chips, pcb’s and other critical
components. In addition the display will show the following message, with the actual
model number displayed in place of model # below.
SLAUGHTER
model # V E R : X . X
The instrument will recall the last setup which was active and the display will show the
parameters which were programmed into the unit. The instrument is now ready for
operation.
B. SETUP PROCEDURE:
1. To select the Memory location on models 2925, 2935, and 2945
Please press the SET key until the display shows
Use the Up/Down arrow keys to select memory locations 1 through 5. After selecting the
memory, press the SET key to view the settings that have been recalled from memory or
to make any changes to these settings.
To store any changes to the settings press the Exit key. The parameters are automatically
updated into the memory location that was selected, when exiting to the test mode.
