OPERATION
16. If the insulation resistance exceeds the high limit setting, but does not exceed the
metering range, the red indicator light will illuminate on the RESET switch and an alarm
will sound. The display will show:
I - H i g h MX XXX . X s
X . XX K V D C XXX . X M
17. If the insulation resistance exceeds the high limit setting, and exceeds the metering
range, the red indicator light will illuminate on the RESET switch and an alarm will
sound. The display will show:
I - H i g h MX XXX . X s
X . XX K V D C > 1 0 0 0 M
18. If the leakage current does not exceed the low limit setting and is within the metering
range the red indicator light will illuminate on the RESET switch and an alarm will
sound. The display will show:
I -L o w M X XXX . X s
X . XX K V D C XXX . X M
19. If the leakage current does not exceed the low limit setting and is not within the
metering range the red indicator light will illuminate on the RESET switch and an alarm
will sound. The display will show:
I -L o w M X XXX . X s
X . XX K V D C < 1 M
