HOT WATER WAND COMPONENTS
ITEM NO. PART NUMBER DESCRIPTION
1 46005-53170 Steam Wandom Grip - Slayer Branded
2 46000-50030 O-Ring for Steam Tip, 1.5 x 6
3 40005-50330 Steam Wand, #3 Tip, Slayer Steam
4 46000-53050 O-Ring for Peek Steam Valve Bushing
5 42000-34710 Fitting, Easy-Align, Compression Tube, Straight Adapter for 1/4" Tube OD x 1/4 - F Pipe, Brass
6 46005-53010 Rear Block for Steam Assembly
7 46005-53030 Compression Spring for Steam Wand
8 46000-53070 Gasket for Steam Valve Brew Actuator, 27mm, Teflon
9 46000-53040 Washer, Flat, M7 Screw Size, 14mm OD, 1.4mm-1.8mm Thick
10 46005-53060 Bushing, 15 X 10.5mm Peek Plastic
11 46005-53110 Steam Seal, Peek Plastic
12 10005-10002 Steam, Wand Socket
13 10005-10008 Steam and Hot Water Lock Nut
