PUMP COMPONENTS & LINES
ITEM NO. PART NUMBER DESCRIPTION
1
30000-20446 Harness, Motor, 2/3 Group, CE
30000-20470 Harness, Motor, 2/3 Group, UL
2 30000-58020 Motor, 1/3 HP, Wired for 220V
3 30000-58060 Pressure Regulator
4 42000-10050 Tee Fitting, M-F-M, 3/8" BSPT Male, 3/8" BSPP Female
5 46000-50130 Gasket for PRV, 3/8", Copper
6 42000-10060 Reducer, 3/8" - M x 1/8" - F
7 46000-50320 Brew Gauge, 20BAR Custom Printed Slayer Logo
8 42000-10010 Extension, Fitting, 3/8"
9 42000-10030 Tee Fitting, 3/8 M/M/M
10 40005-10010 Stainless Steel Hose, 3/8" Fc x CFc 2000mm
11 30000-58030 Pump, 45 GPH
