VXX: Software version.
This symbol means “Caution: read accompanying documents.”
At the end of the product lifecycle, do not throw this product or batteries into the normal
household garbage, but bring it to a collection point for the recycling of electronic
equipment.
Some product materials can be re-used if you bring them to a recycling point. By re-using
some parts or raw materials from used products you make an important contribution to
the protection of the environment. Please contact your local authorities if you need more
information about collection points in your area.
Waste Electrical and Electronic Equipment can have potentially harmful effects on the
environment. Incorrect disposal can cause harmful toxins to build up in the air, water and
soil and can be harmful to human health.
The CE mark applied also indicates that this equipment complies with the requirements of the ROHS
Directive (2011/65/EU) for the Restriction of Hazardous Substances in Electrical and Electronic
Equipment.
Rated Outputs / Voltage/Currents (+/- 20%): Type 374
Parameter 500Ω 1KΩ 1K5Ω
Output RMSV 2.1V 4.0V 5.9V
Output RMSA 4.1mA 4.0mA 3.9mA
Output Frequency 70-80Hz 70-80Hz 70-80Hz
DC Component: Approx. 0 C 0 C 0 C
Positive Pulse Width: 80-100 µs 80-100 µs 80-100 µs
Negative Pulse Width: 80-100 µs 80-100 µs 80-100 µs
Interphase Interval: 100 µs 100 µs 100 µs
Max. Current 30mA 30mA 30mA
The Output Frequency indicates the number of pulses per second transmitted by the controller.
This is measured in hertz, which is indicated by “Hz”.
Output (RMSA) means the maximum output root mean square current for each channel.
Output (RMSV) means the maximum output root mean square voltage for each channel.
English
English
20 21
E
E
XPECTED
XPECTED
SERVICE
SERVICE
LIFE
LIFE
Controller: 5 years
Headset: 3 years
Gel Pads: Approximately 6-10 sessions
!
