Waveform: Symmetrical bi-phasic square waveform when measured into a
resistive load.
Environmental Specifications:
O
perating: Temperature Range: 0 - 35°C (32 - 95°F)
Humidity: 20 - 65 % RH
S
torage: Temperature Range: 0 - 35°C (32 - 95°F)
Humidity: 20 - 85 % RH
Description of your unit’s symbols:
There are a number of technical markings on your unit. These can be
explained as follows:
The unit and belt are manufactured for Bio-Medical Research Ltd, Parkmore
Business Park West, Galway, Ireland.
The unit requires 1 x 3.6 volt (NiMH) DC battery pack DC is indicated by
the symbol:
The Output Frequency indicates the number of pulses per second transmit-
ted by the unit. This is measured in hertz, which is indicated by “Hz”.
Output (RMSA) means the maximum output root mean square current for
each channel.
Output (RMSV) means the maximum output root mean square voltage for
each channel.
This symbol means “Attention, consult the accompanying documents”.
This symbol means type BF applied parts.
This symbol on your unit is to indicate conformity to the require-
ments of the Medical Device Directive (93/ 42/EEC). 0366 is the
number of the notified body (VDE).
SN stands for ‘serial number’. Inside the box, on the back of the unit is the
serial number specific to this unit. The letter preceding the number indicates
the year of manufacture, where “L” denotes 2006, “M” denotes 2007 etc.
The belt’s batch number is represented on the belt packaging, by the num-
ber corresponding with the LOT symbol.
Rated Outputs – Voltage/Currents: E:10 and X:10
Parameter 500Ω 1KΩ 1K5Ω
Output RMSV 6.4V 12.7V 12.7V
Output RMSA 12.7mA 12.7mA 8.5mA
Output Frequency 50-70Hz 50-70Hz 50-70Hz
DC Component: Approx. 0 C 0 C 0 C
Positive Pulse Width: 200-300µs 200-300µs 200-300µs
Negative Pulse Width: 200-300µs 200-300µs 200-300µs
Interphase Interval: 100 µs 100 µs 100 µs
Attention:
This unit can deliver currents in excess of 2mA/cm
2
if used with incorrect
electrodes.
Belt Materials:
Outer material: 100% Nylon, Binding: 82% Nylon, 18% Elastane, Hook &
Loop: 100% Nylon, Foam: 100% Polyurethane
!
0366
1716
technical specifications
battery information
English
Conforms to UL STD 60601-1.
Certified to CAN/CSA.
STD C22.2 NO 601.1
At the end of the product lifecycle, do not throw this product into the
normal household garbage, but bring it to a collection point for the
recycling of electronic equipment.
Some product materials can be re-used if you bring them to a recycling
point. By re-using some parts or raw materials from used products you
make an important contribution to the protection of the environment.
Please contact your local authorities if you need more information
about collection points in your area.
Waste Electrical and Electronic Equipment can have potentially harmful
effects on the environment. Incorrect disposal can cause harmful toxins
to build up in the air, water and soil and can be harmful to human
health.
Charging and Discharging
Your unit is powered by a rechargeable battery pack. The batteries can be
charged and discharged hundreds of times, but it will eventually wear out.
When operating times become noticeably shorter than normal, you should
replace the batteries. Use only Slendertone approved battery packs and
recharge them only with chargers approved for this unit.
If a replacement battery pack is being used for the first time, or if the unit
has not been used for a prolonged period of time, it may be necessary to
connect the charger, disconnect it and then reconnect it to begin charging
the batteries.
If the batteries are completely discharged, it may take several minutes
before the charging indicator appears on the display.
Use the battery pack only for it’s intended use and never use any battery
pack or charger that has been damaged.
Leaving the battery pack in hot or cold places, such as in a car in Summer or
Winter conditions, will reduce the capacity an lifetime of the batteries.
Always try to keep the batteries between 15C and 25C (59F - 77F). A unit
with a hot or cold battery pack may not work temporarily, even when the
batteries are fully charged. Battery performance is particularly limited in
temperatures well below freezing.
Do not dispose of batteries in a fire, as they may explode. Batteries may
explode if damaged. Dispose of batteries according to local regulations.
Please recycle when possible. Do not dispose as household waste.
Do not dismantle or shred cells or batteries. In the event of a battery leak,
do not allow the liquid to come in contact with the skin or eyes. In the event
of such a leak, flush your skin or eyes immediately with water, or seek med-
ical help.
technical specifications
