INFLATE RIGHT™ TECHNOLOGY INSTRUCTIONS:
1. Hold the + or – button for approximately 2 seconds until the display flashes. Set the
required pressure using the + or – buttons, then wait 3 seconds. The display will show
the pressure value to which the tire will be inflated. (Continuously pressing the “+”
or “-“ button will enter into “Fast setting mode”, increasing or decreasing the rate of
target pressure at an increased speed.)
2. Depress and hold the trigger for the inflator to start.
a. The inflator is also equipped with a trigger lock, allowing the user to lock it to prevent
accidental start, or lock it in the “on” position to allow the inflator to be used without manually
depressing the trigger to inflate. The lock has three positions; pushed all the way to the left is
lock (no inflation). In the middle or center position, the trigger is free to engage / disengage.
In the far right position, the trigger will be locked in the on position. To lock the inflator in the
“on” position, depress the trigger and push the lock to the furthest right position. The inflator
will still turn off automatically when desired pressure is reached.
3. When the pressure gauge reaches the pre-set value, the inflator will automatically stop
inflation. Once desired tire pressure is reached, disconnect the air hose.
TRIGGER POSITIONS
LOCKED OFF
Left position “Locked-off”: by default, the control
button will be “Locked-off”; in this position the
inflator will not run.
LOCKED OFF
MANUAL
LOCKED ON
MANUAL
Center position “manual”: squeeze the trigger
button to begin inflation. Inflation will stop
when the trigger is released.
LOCKED ON
Right position “Locked-on”: place control button
in the center position and squeeze the trigger to
start inflation. While trigger is being squeezed,
slide the control button to the furthest right
position. The inflator will now run without
holding the trigger.
