9.2.2 Operation of Long-Range Fuel Tanks
Fuel tank feed selection is enabled by shut-off valves located against
the centre console side wall, close to the pilot’s right knee for aircraft
with standard brakes. For toe-brake configuration, the shut-off valves
are on the top of the centre console. Both arrangements, with shut-
off valves in the closed position, are showing in pictures below.
9.2.3 Fuel System Valve Setup
Location of shut-off valves
The Facet electric pump is activated by the transfer pump switch on
the instrument panel. Either (long range) B tank, left or right can
supply to the main (A tank) in use. Fuel tank feed selection is enabled
by the two shut-off valves, both labelled Tank B on the centre
console. Valve operation is shown in the pictures below for an aircraft
with the toe-brake configuration.
