Sling 4 TSi - 6.3 Centre of Gravity Arms

Sling 4 TSi Section 6
Pilot Operating Handbook
Weight and Balance
Document Number: DC-POH-001-X-F-3.0 Page | 6-2
Revision: 3.0 Date: 2021/07/14
6.3 Centre of Gravity Arms
WARNING
Aircraft CG and MAUW limitations must be adhered to at all times.
NOTE
• GC range is 1847mm (6.060 ft) to 2043 mm (6.703 ft) aft of the
reference datum (18 to 33% of MAC).
• The leading edge of the wing at MAC is 1613 mm (5.292 ft) aft of
the reference datum.
•
The MAC is 1302 mm (4.272 ft).
2043 Max AFT CG
1847 Max FWD CG
464 NW
1800 Fuel
1902 Front Seats
2236 Main Undercarriage
2948 Rear Seats
3288 Luggage
3288 Luggage Extension
Datum: 52mm AFT OF FRONT FACE OF ENGINE PROPELLER FLANGE
