Storage Case
1. Charging: red display when connected to the power supply to
charge RX/TX, and green display when RX / TX is fully charged.
2. Port: with USB-C charging port, and built-in USB-A charging cable
at the bottom of the storage case.
Operating Instructions
Transminer
Mount the transmitter to the collar via the back clip so that
the built-in microphone points in the direction of the audio
source.
(Note: In the process of use, for better concealment, it is
recommended that the back clip is fixed towards the
outside for use)
Use an external microphone
Plug the 3.5mm TRS microphone input cable into the
transmitters 3.5mm TRS external microphone jack. Clip the
transmitter to your belt via the back clip, then clip the lavalier
microphone on the other end to your collar.
(Note: When using an external microphone, the built-in
microphone will automatically turn off)
Receiver
Method for using with the camera
Clip the receiver to the camera's cold shoe mount via the
back clip. Connect the receiver to the camera via 3.5mm
TRS-TRS cable. Plug the headphones into the headphone
monitor hole for monitoring.
