SmallRig MagicFIZ - Interface and Operation Guides; Controller and Module Interfaces

Interface Instruction
Instruction of
Motor Interface
Instruction for Wireless Handwheel
Controller Interface (single control)
Instruction for Electronic Controller Module Interface
Disconnected
Status
Wireless
Status
Wired
Status
Channels
Motor Number
Input Voltage
Motor Position
Battery Status
Safety Lock
Channels
Motor Number
Status of A Mark
and B Mark
Motor Position
Communication
Status
REC Prompt
Power-on Status
Channels
Motor Number
Status of A Mark
and B Mark
Motor Position
Communication Status
5.2 Directly connect the Wireless Handwheel Controller and Electronic Controller Module with the
camera BLE to wirelessly control the REC recording.
Sony NikonCanon
A7C, A7RⅢ, A7RIV, A7 IV, FX3,
A7SⅢ, A9, A9 II, RX100 Ⅶ,
DSC-RX100M7, A6100,
A6400, A6600, ZV1, ZV-E10
Z50
EOS 90D, EOS M6 Mark II
EOS M50, EOS R, EOS R5
EOS RP, G7X Mark III
7
