Smart Lock H50-TYW User Manual

1
1. Introduction
1.1.Lock structure
1.2.Packing List
Check the following drawing to check whether the package contains all the parts
NO
Name
Qty
NO
Name
Qty
1
Front Pane
1
9
Sliding Screws:16*5mm
2
2
Back Panel
1
10
Mortise Screws:10*5
(For Aluminum Door)
4
3
Mortise:55*72
1
11
Mortise Screws:25*4mm
(For Wooden Door)
4
4
Card
3
12
M5*20mm Screw for
Door Thickness 35-50mm
1
5
Mechanical Key
2
13
M5*30mm Screw for
Door Thickness 30-65mm
1
6
Waterproof Rubber
Plate
2
14
M5*50mm Screw for
Door Thickness 50-65mm
1
7
Screw
Stubs:M5*30mm
2
15
User Manual
1
8
Strike&Strike Box
1+1
16
Chuck
1

Smart Lock H50-TYW Specifications

General

Brand	Smart Lock
Model	H50-TYW
Category	Locks
Language	English
