Smart Lock H50-TYW - Installation Diagram

4
2.2. Installation Diagram(For 5572)
Step 1 Install Mortise
Step 2 Install Sliding Screw Casing
Step 3 Connect Front and Back
Panels
Step4 Install Back Panel
Step5 Install the Battery
Keep arrow
direction(shows in
image) always upward.
