Operating Controls
1 +24V, PB, GND - used for connecting 2 or 3 wire
Photo Electric beam.
2 PE Dipswitch setting
- set dipswitch down when
connecting Photo Electric Beams.
3 GND, PB
- used for external push button input.
4 Motor and limit inputs.
5 RF Receiver Board - 433.22MHz AM FSK Receiver.
6 Down Force Adjustment
- used to adjust closing
obstruction force margin.
7 Auto-Close (AC) Dipswitch Setting
- set dipswitch
up to activate auto close function.
(1 min. set close time).
8 Right Hand/Left Hand Dipswitch - used during
installation. Dipswitch is factory preset for RH, for LH
installation set dipswitch up.
9 24 Volt AC Input.
-5-
10 24 Volt Battery Input
11 Learn Button - used to store transmitter into memory.
12 Learn LED
- indicates learn/operate mode of
transmitter.
13 Fuse
- main fuse (240V 3A)
14 LED Light.
15 Operate Button
- Open/Stop/Close function.
16 Open Limit Cam
17 Close Limit Cam
18 Open/Close Limit Switches
19 Green Engage Cord
- used to engage the door for
automatic operation.
20 Red Disengage Cord
- used to disengage the door
for manual operation.
