Maintenance
Important
Connections
Pump Cleaning / Troubleshooting
Filter cover can simply be pulled apart as shown.
Turn o impeller cover to release as shown, impeller
can be easily removed
Remove lter material and rinse in water.
Rinse all parts thoroughly in water.
Ensure connections from both solar panels to pump
are water tight.
If the pump is not working immediately, try the
following for a manual start. Remove the
pump cover. Remove the impeller cover, face
the panel to the sun, and start manually
spinning the impeller clockwise, this can
take 1-3 minutes.
!
Sculpture Style Fountain Assembly
1
2
2
3
4
1. Attach the main bowl to the pedestal. Align the
marks and turn to lock in place.
2. Place the solar panels in the recesses provided
running the cables through the holes in the side.
3. Connect the solar panels to the pump taking care
to ensure the connectors are water tight. Slightly
twist when pushing together, ensure the red o-ring
remains in it’s groove and is not displaced. (see
images below)
4. Connect the hose from the pineapple to the pump
and lower it into place. Ensure the pump and cables
are nearly stored in the recess provided.
5. Fill the main bowl with water.
Note: Water must be regularly topped o. We
recommend regularly changing the water to ensure
it remains clean and free from debris.
5
