Typical Programs(Monday - Friday
1 Heat Cool 2 Heat Cool 3 Heat Cool 4 Heat Cool
a Default Program 6:00am 20 26 8:00am 16 29 4:00pm 20 26 10:00pm 16 28
b Typical worker (9:00am - 5:00pm) 6:30am 21 23 8:00am 7 26 5:00pm 21 23 10:30pm 7 35
c Home all day 7:00am 21 23 7:00am 21 23 7:00am 21 23 11:00pm 15 35
d
lways off(used in override function o 6:00am 7 35 8:00am 7 35 4:00pm 7 35 10:00pm 7 35
Typical Programs(Monday - Friday) 1 Heat Cool 2 Heat Cool 3 Heat Cool 4 Heat Cool
a Default Program 6:00am 20 26 8:00am 16 29 4:00pm 20 26 10:00pm 16 28
b Typical worker 9:00am 21 23 11:30am 18 26 5:00pm 21 23 11:00pm 7 35
c Home All Day 8:00am 21 23 8:00am 21 23 8:00am 21 23 11:00pm 15 35
d
lways off(used in override function o 6:00am 7 35 8:00am 7 35 4:00pm 7 35 10:00pm 7 35
Manual Operation of the
Thermostat
Press and hold the up button
Set the desired temperature
There will be two temperatures
shown on the display - The top one is
the set temperature and the bottom is
the room temperature
Press and hold the down button
Set the desired temperature
There will be two temperatures shown
on the display- The top one is the set
temperature and the bottom is the
room temperature
Press the hold button twice.
"Hold" will be displayed on the
screen
This will hold the temperature
indefinately until the thermostat
reasches it's temperature, is
turned off or if the "hold/ret"
button is pressed (this will
resume to the programming)
Press the hold button twice.
"Hold" will be displayed on the
screen
HO L D/ RE T HO L D/ RE T
Do you want
to Heat or
Cool?
Move Slide switch to heat
position
Move Slide switch to Cool
position
Heat
Cool
To Next Page
