Introduction of the New smart fortwo coupé and smart forfour | Model Series 453
Brake system
Chassis
View of front brake system (internally ventilated)
Brake system
The brake system of model series 453 is designed as a hyd-
raulic dual-circuit brake system with diagonal split.
The brake control system of the brake system comprises the
familiar functions of ABS, ESP, ASR, BAS, GMR and Hill-
Start Assist. The Crosswind Assist function is a new feature
in this segment.
Parking brake with manual operation
As on the predecessor model series, the new smart uses a
lever-type handbrake which acts on the drum brakes of the
rear axle.
Cable slack adjustment can be carried out manually on mo-
del series 453 under the handbrake lever trim.
View of rear brake system
View of brake control system
– This printout will not be recorded by the update service. Status: 06/2014 –
