72
P82.10-7637-00
P82.10-7638-00
P00.10-5670-00
Introduction of the New smart fortwo coupé and smart forfour | Model Series 453
Exterior lights
Lights
Front lamp unit (standard)
Front lamp unit (SA)
Front lights
Headlamps
The new smart is equipped with H4 halogen headlamps as
standard. The main headlamp is divided into two segments.
The high and low beam are positioned centrally, with the
daytime running light function underneath. The turn signal
indicators are arranged separately outside of the main head-
lamp, while the optional front fog lamps are housed in the
bumper.
A halogen headlamp, which differs from the basic headlamp
due to a different daytime running light design, is available
as special equipment in combination with certain equipment
packages.
This is a particularly eye-catching feature because a honey-
comb structure in the headlamp is projected using white
LEDs when the vehicle is opened and closed.
The high beam and low beam functions are still positioned
centrally. The turn signal indicators and front fog lamps are
also in the same position as on the basic version.
Headlamp range adjustment
The new smart is equipped with manually-operated electric
headlamp range adjustment. The headlamps are adjusted
using a selector wheel on the le of the instrument panel
next to the steering wheel.
Front fog lamps
The optional front fog lamps are located in the bumper under
the headlamps.
– This printout will not be recorded by the update service. Status: 06/2014 –
