66 Introduction of the New smart fortwo coupé and smart forfour | Model Series 453
Overall network
Networking
Telematics CAN
A2 Radio
A2/13 Sound system amplifier
control unit
A40/3 smart Radio Multimedia
Navigator
A40/3s1 ON/OFF button
A40/3s2 Home button
A40/3s3 Mute function and menu
scroll button
N24 Multimedia operating unit
N93/1 Audio gateway control unit
N112/2 Telematics services com-
munications module
Interior CAN
A1 Instrument cluster
A2 Radio (only valid without
multifunction steering
wheel and without sound
amplifier)
A40/11 Multifunction camera
N2/10 Supplemental restraint sys-
tem control unit
N3/10 ME-SFI [ME] control unit
(M281)
N10/10 Center SAM control unit
N10/11 Driver-side SAM control unit
N22/1 Climate control control unit
N30/4 Electronic Stability Program
control unit
N68 Electric power steering con-
trol unit
N93/1 Audio gateway control unit
N93/2 Distance function gateway
N112/2 Telematics services com-
munications module
X11/4 Diagnostic connector
Drive train CAN
N3/10 ME-SFI [ME] control unit
(M281)
N15/5 Electronic selector lever
module control unit
N15/13 Dual clutch transmission
control unit
Chassis CAN
N30/4 Electronic Stability Program
control unit
N49 Steering wheel angle sensor
Front end CAN
A89 Controller unit for distance
warning function with radar
sensor
N93/2 Distance warning function
gateway
AC operation LIN
N20 Climate control operating
unit
N22/1 Climate control control unit
Rain and light sensor LIN
B38/2 Rain/light sensor
N10/11 Driver-side SAM control unit
Additional instruments LIN
A1 Instrument cluster
A15 Additional instruments
– This printout will not be recorded by the update service. Status: 06/2014 –
