No. Consumer Current Colour cod-
ing
10 Central control unit 20 A Yellow
11 Central control unit 15 A Blue
12 Central control unit 10 A Red
13 Central control unit 15 A Blue
14 Power windows (automatic reversing feature) 30 A Green
15
ESP
®
, transmission control unit
5 A Brown
16 Interior lighting 10 A Red
17 Immobiliser 3 A Violet
18 Electrical exterior mirror 5 A Brown
19 Brake lamps 10 A Red
20 Cruise control, radio, belt warning 15 A Blue
21 Not smart electric drive: central control unit, fuel
pump, injection
15 A Blue
22 Rear window wiper 15 A Blue
23 smart electric drive only: power supply control
unit
40 A Orange
24 ‑ ‑ ‑
25 Power supply control unit 30 A Green
26 Radio 20 A Yellow
27 Daytime driving lamps 5 A Brown
28 12 V socket, cigarette lighter 15 A Blue
29 Power supply control unit 5 A Brown
30 Forward collision warning 15 A Blue
31 Rear fog lamps ‑ ‑
32 Radio, central control unit 15 A Blue
33 Tail lamps, front foglamps, hazard warning lamp
button, locking button, headlamp range control,
power windows, licence plate lighting, radio,
control unit for heating or climate control system,
cruise control, limiter, parking aid button, pro-
gram selector button, tailgate release, Lane Keep-
ing Assist camera, automatic start/stop system
button
25 A Cyan
34 Power supply control unit 25 A Cyan
35 Headlamps, daytime driving lamps 25 A Cyan
204
Fuse allocation
>> Technical data.
