TEST AND ADJUSTMENT VALUES FOR THE BATTERY
CHARGE BATTERY - AR54.10-P-1130MCC
MODEL 451.3/4
REMOVE/INSTALL MAIN FUSE OF SECONDARY AIR INJECTION PUMP - AR54.15-P-
0050MCU
MODEL 451.3/4 (except 451.391 /491)
replaced.
5 Check battery AR54.10-P-1129-01A
Cold test current
Midtronics battery tester
gotis://E_15/54_02.0
*BE54.10-P-1002-01A
Install
6 Install foot support on
passenger side
Left-hand drive vehicles AR68.30-P-1340MCC
Right-hand drive vehicles AR68.30-P-1340MCE
Number Designation 42 AH 60 Ah VRLA 61 AH 62 AH
BE54.10-P-1002-
01A
Cold test current as per EN A 340 680 540 480
Remove/install
Risk of explosion caused by oxyhydrogen
gas. Risk of poisoning and caustic burns
caused by swallowing battery acid. Risk of
injury caused by burns to skin and eyes
from battery acid or when handling
damaged lead-acid batteries
No fire, sparks, open flames or
smoking. Wear acid-resistant
gloves, clothing and glasses. Only
pour battery acid into suitable and
appropriately marked containers.
AS54.10-Z-
0001-01A
Notes on battery
AH54.10-P-
0001-01A
Notes on AGM battery Model 451.334/380/480
AH54.10-P-
0002-
01MCC
1 Remove battery
Pull vent hose out of the hole in
the battery recess.
Left-hand drive vehicles
AR54.10-P-
0005MCC
Right-hand drive vehicles
AR54.10-P-
0005MCE
2
Charge battery according to operating
instructions of charger
With a battery which is not low-
maintenance remove the stop plugs,
check acid level and correct if
necessary.
3 Install in the reverse order
2010 Smart Fortwo Passion
2009 ACCESSORIES & BODY, CAB Electrical System, Equipment & Instructions - Fortwo (Cabrio)
15 октября 2019 г. 19:12:10 Page 22 © 2011 Mitchell Repair Information Company, LLC.
