REMOVE/INSTALL FRONT SAM CONTROL UNIT - AR54.21-P-1254MCU
MODEL 451.3/4
l Weight Sensing System
(WSS) control unit (N110)
with code (494) USA version
Starter-alternator control unit
(N129) with model
451.334/380/480
l Electronic selector lever
module control unit (N15/5)
l Restraint systems control unit
(N2/7)
l Heater and A/C operating unit
(N23) with code (I01) A/C
Plus
l CDI control unit (N3/9) with
engine 660
l ME-SFI [ME] control unit
(N3/10) with engine 132
l SAM control unit (N10/10)
l Automated manual
transmission control unit
(N15/6)
l ESP control unit (N47-5)
l Steering assist control unit
(N68)
l TPM [RDK] control unit
(N88) with code (494) USA
version
5 In the menu for the selected
control unit, choose the "Initial
startup" menu item and confirm
with the "F3" button
6 Confirm "Notes for initial startup
of control unit" with "F2" button
7 Select the "online (networked
STAR DIAGNOSIS unit)" menu
or "offline (no networked STAR
DIAGNOSIS unit)" menu and
start by pressing the "F3" button
8 Follow the further instructions in
DAS.
9 Close Star Diagnosis
2010 Smart Fortwo Passion
2009 ACCESSORIES & BODY, CAB Electrical System, Equipment & Instructions - Fortwo (Cabrio)
15 октября 2019 г. 19:12:10 Page 36 © 2011 Mitchell Repair Information Company, LLC.
