HGM6110/6120 AUTO START MODULE
HGM6110/6120 Auto Start Module ISSUE 2.0 2008-10-27 Page 15 of 24
Num
Parameter Range Default
Remark
22 Gens over volt (30-360)V 264
When generator voltage is over than
the point, generator over voltage is
active. When the point is 360V,
generator over voltage is disabled.
23 Gens under volt (30-360)V 196
When generator voltage is under
than the point, generator under
voltage is active. When the point is
30V, generator under voltage is
disabled.
24 Under speed (0-6000)RPM 1200
When the engine speed is under
than the point and hold great than
10 seconds, generator under speed
is active.
25 Over speed (0-6000)RPM 1710
When the engine speed is over than
the point and hold great than 2
seconds, generator over speed is
active.
26 Gens under freq 0-75.0Hz 45.0
When generator frequency is low
than the point, generator low
frequency and hold great than 10
seconds is active.
27 Gens over freq 0-75.0Hz 57.0
When generator frequency is over
than the point and hold great than 2
seconds, generator over frequency
is active.
28 High temperature (80-140)℃ 98
When engine temperature sensor
value is large than this point and
remain for 2 seconds, send out
shutdown alarm. When the value is
140, send out warning alarm. (It’s
suited for engine temperature
sensor only).
29 Low oil pressure (0-400)kPa 103
When engine oil pressure sensor
value is less than this point and
remain for 2 seconds, send out
shutdown alarm. When the value is
zero, send out warning alarm. (it’s
suited for oil pressure sensor only)
30 Low fuel level (0-100)% 10
When fuel level sensor value is less
than this point and remain for 10
seconds, send out warning alarm.
